1.3MP PYTHON1300 210FPS USB3.0 Global Shutter Camera

PYTHON1300 Global Shutter Camera is a high-performance machine vision camera designed for a range of demanding applications. With a resolution of 1.3 million pixels, the PYTHON1300 captures sharp, detailed images, ideal for precision inspections and identification tasks. Operating at an impressive 210 frames per second (FPS), the camera offers superb performance, ensuring that even the fastest moving objects can be captured with ease.

The PYTHON1300 is compatible with GenlCam and USB3 Vision standards, seamlessly integrating into a range of machine vision systems. Additionally, it supports HALCON, Vision Pro, and Labview programming interfaces, enabling users to customize their machine vision solutions to suit specific needs. The camera is also powered by an NVIDIA TX1 or TX2 processor, and can run on both Windows and Linux operating systems, providing maximum flexibility for users.

With a global shutter, the PYTHON1300 delivers uniform exposure and minimizes distortions in fast-moving scenes, making it an excellent choice for a range of machine vision applications including motion analysis, high-speed counting, and automated inspection. Featuring a compact design and USB3.0 connectivity, the PYTHON1300 is a cost-effective solution for any machine vision project.

Product Feature

• Resolution 1.3M.
• Support GenlCam and USB3 Vision.
• Support HALCON、 Labview .
• Support NVIDIA TX1、 TX2；windows；Linux.​

Camera Parameters

Model:MARS1300-210UC/UM
Sensor:PYTHON 1300
Shutter:Global Shutter
Sensor Size:1/2"
Sensor Type:CMOS
Resolution:1280 px x 1024 px
Pixel size:4.8 μm x 4.8 μm
Frame Rate:210 fps
Mono/Color:Color and Mono
Lens Mount:C-mount(CS-Mount can be customized)
SDK:Mars Series Camera Secondary Development Kit（iCentral）or Third-party Software meeting with USB3 Vision Protocol
Operating System:Windows，Linux
Conformity:USB3 Vision and GenICam

Package List

1 x Industrial Camera (No Include Lens)
1 x I/O Cable
1 x standard Date Cable（Optional inquire length.）

Mars1300-210um/uc Download

​ ​
