![BTL 125 Series Bi-Telecentric Lenses C-Mount for 2/2.5" Sensors](http://shop.visiondatum.com/cdn/shop/files/zero_distortion_200mm_208mm_C-mount_TelecentricLenses_For_sensor_up_to_62mm_vision_datum_telecentric_lens_for_industrial_measurement2_4.jpg?v=1721787645&width=1445)
Key Features
- High telecentricity for thick object imaging.
- Excellent resolution for high resolution cameras.
- Simple and robust design for industrial environments.
- Optimized for 1/2.5"~1.1" C-Mount cameras;
- Largest FOV from 26mm up to 300mm;
- Low distortion, good telecentricity, big aperture and big depth of field for high end application.
Key Parameter
- Support 1/2.5" Sensor
- For Area Scan Camera
- C Mount/F 4.2
- Max. Sesnor Size 7.2(1/2.5")
Note 1:The back focal length of model with (LM) is adjustable.
Note 2:Warm tips: The above DOF is just theoretical value at the ideal aperture (eg. ±763@F11). Actual DOF or the DOF what you need, please check with our sales engineer before order cfm.
