640×512 257.8fps GigE Vision SWIR Camera 400–1700nm | Sony IMX991 with Cooling iBX-SWG991A/J

💳 Transaction Fees Are Non-Refundable
When a refund is issued, please note that payment processing platforms do not return their service fees. These fees are not charged by our store, but by third-party providers (Shopify & PayPal).The handling fee will be deducted from a certain percentage of the order amount.

Shopify Payments: 1% transaction fee is not refundable.
PayPal: Charges a 4.4% + $0.30 USD fee, which is also non-refundable.

These amounts will be deducted from your refund total.

💬 Refund Policy – Important Fee Notice
We understand that sometimes you may need to cancel an order. Here’s what you need to know about refunds on our website:

🧾Notice for U.S. Customers
Due to applicable tariffs, please email your company name and FedEx, UPS, or DHL account number to wcss02@visiondatum.com after placing your order. (U.S. customers only)

✅ Order Production Policy
All of our products are made to order or prepared specifically based on your purchase. We kindly ask customers to confirm their needs before placing an order. If you need assistance or further clarification before ordering, feel free to contact us - we’re here to help!

Q: What is the spectral range of IMX991?
A: The Sony IMX991 sensor offers a spectral response range of 400nm to 1700nm, covering both the visible and short-wave infrared (SWIR) spectrum. This wide range enables imaging applications such as semiconductor inspection, silicon wafer analysis, spectroscopy, material sorting, and machine vision.

Q: Which sensor does this camera use?
A: This camera is equipped with the Sony IMX991 InGaAs sensor, featuring a resolution of 640 × 512 pixels and a 5μm pixel size. The sensor delivers high sensitivity, low noise performance, and excellent image quality across the 400–1700nm wavelength range.

Q: Can SWIR cameras see through silicon?
A: Yes. SWIR cameras can image through silicon because silicon becomes increasingly transparent at wavelengths above approximately 1100nm. This capability allows SWIR cameras to reveal internal structures, defects, and packaging features that are not visible with standard visible-light cameras, making them ideal for semiconductor inspection and failure analysis.

Q: What is a SWIR camera used for?
A: SWIR cameras are used in a wide range of industrial and scientific applications, including semiconductor inspection, machine vision, spectroscopy, solar cell inspection, laser beam analysis, defense imaging, agricultural monitoring, and quality control. Their ability to capture information beyond the visible spectrum makes them valuable for detecting features that conventional cameras cannot see.

Q: Why use TEC cooling in a SWIR camera?
A: TEC (Thermoelectric Cooling) helps reduce sensor noise and improve image stability by maintaining a controlled detector temperature. This is especially beneficial for long exposure imaging, low-light environments, and precision measurement applications where image quality and consistency are critical.

Q: How do I integrate a SWIR camera into a machine vision system?
A: SWIR cameras can be integrated into machine vision systems through standard industrial interfaces such as USB3.0 or GigE Vision. They can be connected to industrial PCs, image processing software, frame grabbers, and automation platforms. Depending on the application, the camera can be combined with SWIR lenses, illumination sources, and machine vision software for inspection, measurement, and process monitoring tasks.

Q: What is the difference between USB3.0 and GigE SWIR cameras?
A: USB3.0 SWIR cameras provide high-speed data transfer and low latency, making them ideal for laboratory, R&D, and local image acquisition. GigE SWIR cameras support longer cable distances, multi-camera systems, and industrial network integration, making them well suited for factory automation and machine vision applications.

Q: What industries commonly use Sony IMX991 SWIR cameras?
A: Sony IMX991 SWIR cameras are widely used in semiconductor inspection, machine vision, scientific research, solar cell testing, electronics manufacturing, and defense applications. Their 400–1700nm spectral sensitivity enables imaging beyond the visible spectrum for advanced inspection and analysis tasks.
